Active Studio Monitor
- 3 Way System
- Maximum sound neutrality and transient response
- Uniform directivity
- Precise bass reproduction down to 34 Hz
- LF input with extremely low distortion electronically-balanced input stage
- Magnetically shielded
- Variable adaptation within three frequency ranges
Technical data:
- Peak power: 210 W (Woofer), 90 W (Midrange), 90 W (Tweeter)
- Continuous power: 150 W (Woofer), 70 W (Midrange), 70 W (Tweeter)
- Free-field frequency response: 34 Hz - 21 kHz, +/- 3 dB
- Total harmonic distortion (THD)
- Sound pressure level: 120.2 dB SPL at 1 meter in half space at 3% THD
- Membrane dimensions: Woofer 8 1/4'', Midrange: 3'', Tweeter: 1''
- Controller-Technology: Analog, active
- Crossover: Crossover frequency 650 Hz/2 kHz
- 24 dB/Okt
- Equalization: Bass: 0..-7.5 dB, Midrange: 0..-4.5 dB, Treble: 1..-2 dB, each adjustable in 4 steps
- Audio input (analog): XLR> 10K ohms electronically balanced
- Dimensions: 253 x 383 x 292 mm
- Weight: 13.0 kg
- Mounting option: 2 x M8 side
- Colour (standard): anthracite (RAL 7021)
- 1 Piece: left speaker (optional: Right speaker, not included)
