ctive Studio Subwoofer
- With DSP and fully redundant AES67/ST-2100 audio network interface
- 10'' Ultra long excursion woofer
- Power: 256 W
- Maximum level: 105.0 dB
- Frequency range: 18 - 750 Hz (+ 3 dB)
- 4 Different LFE modes selectable
- Crossover frequency: 80 Hz
- Acoustic control with 8 fully parametric filters via the Neumann.Control app
- FIR phase correction for connected analogue Neumann monitors via optional MA 1 (not included)
- A switchable stand-by mode
- NMOS IS-04 (detection & registration) and NMOS IS-05 (connection management)
- DANTE compatibility for receiving DANTE AES67 streams
- Analogue inputs / outputs in XLR
- Digital inputs / outputs in BNC (75 Ohm, AES3)
- 2 x Ethernet interface
- An optional control and system setting via Neumann.Control iPad App
- An automatic calibration incl. connected Neumann monitors via optional MA 1 software (MAC/PC)
- Dimensions: 383 x 330 x 383 mm
- Weight: 19.5 kg
